Introducing our Mini USB 2.0 to USB-C Panel Mount Cable – the pinnacle of quality and connectivity.
With a Mini 5PIN USB 2.0 male connector and screw-locking USB 2.0 Type-C female connector, enjoy secure connections.
Crafted with precision, featuring gold-plated contacts and nickel-plated shell for durability.
Effortless installation with a 17mm hole pitch and slim 4.5mm outer diameter.
Supports high-speed USB 2.0 devices with a transfer rate of 480Mbps.
Compliant with RoHS and REACH standards, ensuring quality and environmental responsibility.
Its specifications:
- Connector 1: Mini 5PIN USB 2.0 male
- Connector 2: USB 2.0 Type-C female with screw locking
- Gold plated contact, Nickel plated shell
- Nut and Screw type: M3 nickel plated
- Hole Pitch: 17±0.5mm
- Cable Conductor: Bare Copper
- Wire Gauge: 28/24AWG
- Outer Diameter: 4.5±0.2mm
- Shielding: Aluminum foil, Braiding
- Housing: Injection molding
- Jacket: PVC
- Support high speed USB 2.0 devices and the transfer rate reaches to 480Mbps
- Backward compliant with full-speed USB 1.1 (12 Mbps) and low speed USB 1.0 (1.5 Mbps)
- Compliance: RoHS, REACH
